Seed cleaning machine is used for cleaning and grading seeds, grains, cereals, beans, species and other granule material.
After fed into the machine by bucket elevator, the dust and light impurity were removed by air aspiration system, and then materials enter to sieving trunk which has multi sieve layers, finally, the material was graded to a different level by size, at the same time all the oversize and undersize impurities were removed.
| Model | 5XZC-3B | 5XZC-5DH | 5XZC-7.5D | 5XZC-15 |
|---|---|---|---|---|
| Dimension (L×W×H) mm | 3970×1800×2750 | 4970×1900×3100 | 5600×2100×3200 | 5600×2100×3200 |
| Dimension of sieves mm | 1250×800 | 2000×1000 | 2400×1250 | 2400×1500 |
| Capacity kg/h | 3000 | 5000 | 7500 | 10000 |
| Weight kg | 1200 | 1600 | 1700 | 1800 |
| Power Kw | 4.25 | 7.74 | 10.1 | 10.5 |
| Remarks | Dust reducer | Cyclone dust separator | ||
A: It is designed for cleaning and grading wheat, corn, mung beans, vegetable seeds, grains, cereals, beans, and other granule materials.
A: After the elevator feeds materials into the machine, dust and light impurities are removed by an air aspiration system. The materials then enter a multi-layered sieving trunk for size grading while removing oversize and undersize impurities.
A: Yes, we customize various sieve sizes and layers to fit a wide range of applications and ensure high grading efficiency for different seeds.
A: The capacities range from 3,000 kg/h up to 10,000 kg/h depending on the selected model (5XZC-3B, 5XZC-5DH, 5XZC-7.5D, and 5XZC-15).
A: The machines are equipped with either a dust reducer or a cyclone dust separator to capture dust and protect the working environment.
