| Kneading bowl | 300g kneading bowl, the program recognizes the bowl type and automatically calls the corresponding program, without operator selection |
| Software operating system | win7, win10 and other 64-bit operating systems |
| Computer interface | RJ45 Ethernet interface, support 10M/100M adaptive network connection speed, suitable for long-distance data transmission; It can also be connected to a wireless router to achieve wireless data transmission |
| The program has the function of silt curve bandwidth adjustment to ensure that the silt curve bandwidth meets the general requirements | |
| All original data can be exported to Excel files for user data exchange, users can use other tools to reproduce the drawing and experimental data | |
| overload protection function | alarm and stop when the stirring torque exceeds 1000FU to protect the safety of instruments and personnel |
| Multiple safety protection measures | double button start, open cover stop |
| Torque measurement method | dynamic electronic torque sensor, accuracy level 0.2 |
| Display up to 12 silty maps simultaneously for easy comparison of nuances | |
| Data format | The analysis results are saved in sqlite database format for easy access |
| Automatic drawing | the intelligent program senses the action of the instrument and automatically starts the drawing |
| Main mixing blade speed | (63±2)r/min |
| The speed ratio of main and auxiliary stirring blades | 1:1.5 |
| Unit torque | 300g pot: (9.8±0.2) mN · m/F.U |
| Coordinate range | horizontal coordinate 0-45min; The ordinate is 0-1000FU |
| Horizontal speed | (1.00±0.01) cm/min |
| Working temperature of kneading bowl | (30±0.2)℃ |
| The maximum pressure of water bath | 40mbar, and the maximum flow rate is 15L/min. 300g kneading bowl, water flow rate is not less than 2.5L/min |
| Kneading bowl Model | 300g kneading bowl |
| Sample size | 300g(with 300g kneading bowl) |
| Power supply | AC220V 50Hz, motor power: 0.2Kw |
We have some products in stock, you can take away the products after you arrange the payment; If we don't have the products in stock you want, we will start production once getting the payment.
The free warranty is one year from the date of commissioning qualified.
Of course, welcome to visit our factory if you come to China.
Generally, our price is valid within one month from the date of quotation. The price will be adjusted appropriately as the price fluctuation of raw material in the market.
This depends on the quantity. Normally, for the mass production, we need about one week to finish the production.
Yes, we provide comprehensive laboratory solutions, including laboratory design, instrument selection, customization, installation, training, and maintenance.
